TRENDnet’s 60 W Single Output Industrial DIN-Rail Power Supply, model TI-M6024 (Mean Well MDR-60-24), supplies up to 60 Watts of power to industrial PoE equipment such as switches, network cameras, and WiFi access points. This power supply comes with an integrated DIN-rail mount and overload current protection

60 Watt Power

Provides up to 60 Watts (24 V, 2.5 A) of power for PoE devices such as switches, network cameras, and access points

Overload Protection

Overload/short circuit/over voltage protection

Passive Cooling

Cooling by free air convection

Full Load Test

This power supply undergoes a 100 % full load burn-in test

DIN-Rail Mount

Metal enclosure with integrated DIN-rail mount

Extreme Temperatures

Rated for an operating temperature range of -20 to 70 °C (-4 to 158 °F)

Electro Magnetic Emission/Immunity

Compliance to Class B, heavy industry level, and criteria A

LED Indicator

LED indicator confirms power to the unit

SPECIFICATIONS

Interface
  • Input: 100-240 V AC, 50/60 Hz, 1.8 A 120-370 V DC
  • Output: 60 Watts, 24 V, 2.5 A
  • DIN rail: TS-35/7.5 or 15
Housing
  • Metal case
  • DIN-rail mount
  • LED indicator confirms power to the unit
Special Features
  • DC OK relay contact
  • Short circuit/overload/over voltage protection
  • Protection type: shut down and repower
Operating Temperature
  • - 20 to 70 °C (- 4 to 158 °F)
Operating Humidity
  • Max. 90 % non-condensing
  • 2,992,000 hours
Dimensions
  • 40 x 100 x 90 mm (1.6 x 3.9 x 3.5 in.)
Weight
  • 300 g (10.6 oz.)
Certifications
  • CE
  • UL 508
  • UL 60950-1
  • CB 60950-1
  • TUV EN60950-1
  • Class I, Div. 2 hazardous locations T4
Warranty
  • 1 year

PACKAGE CONTENTS
  • TI-M6024
