The Optoma X600 will make your presentations shine with its powerful 6000 lumens bright output and stunning 10,000:1 contrast ratio. It delivers amazingly bright XGA resolution presentations with vibrant colors and sharp, clear text, graphics and video. Easily provides the brightness level necessary for use in medium / large rooms with ambient light – including meeting rooms, classrooms, and lecture halls.
The Optoma X600 features an impressive array of connectivity options and includes, Crestron RoomView for over the network control and management of up to 250 projectors. Perfect for large scale enterprise installations in business and educational environments.
Main Features
OPTICAL/TECHNICAL SPECIFICATIONS
Display Technology Single 0.55" DC3 DMD DLP® Technology by Texas Instruments™
Native Resolution XGA (1024 x 768)
Maximum Resolution WUXGA (1920 x 1200)
Brightness 6000 lumens
Contrast Ratio 10,000:1 (full on/full off)
Displayable Colors 1.07 Billion
Lamp Life and Type* 3500/2500 Hours (STD/bright)
Projection Method Front, rear, ceiling mount, table top
Keystone Correction ±15° Vertical
Uniformity 85%
Aspect Ratio 4:3 Native, 16:9 compatible
Throw Ratio 1.8–2.1:1 (distance/width)
Projection Distance 3.28’–39.4’ (1.0–12 m)
Image Size (Diagonal) 23.4"–300" (0.59–7.62 m)
Projection Lens F=2.6-2.81, f=26.9-29.84 mm, 1.2x manual zoom and focus
Offset 112%
Audio 3-Watt speaker
Noise Level 28dB
Remote Control IR remote mouse control with laser
Operating Temperature 41–104°F (5–40°C), 85% max humidity
Power Supply AC input 100–240V, 50–60Hz, auto-switching
Power Consumption 380W (bright), 300W (STD), <1W (standby)
Warranty 3-Year Optoma Express Service, 1-Year on Lamp
COMPATIBILITY SPECIFICATIONS
Computer Compatibility WUXGA, HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA resized, VESA, PC and Mac compatible
3D Compatibility† Supports all HDMI 1.4a mandatory 3D format, side-by-side format and top and bottom format. 3D glasses are needed and sold separately.
Vertical Scan Rate 50–85Hz, 120Hz, 144Hz
Horizontal Scan Rate 15, 31–90KHz
User Controls Complete on-screen menu, adjustments in 26 languages
I/O Connection Ports Display port, Two HDMI, Two VGA-in, VGA-out, S-video, composite video, stereo RCA, audio-in, stereo audio-out, RS-232C, RJ45, 3D-sync, USB and 12V trigger
Loop Through (Audio, VGA) Monitor: D-Sub 15 pin VGA output Audio-out: Stereo 3.5 mm mini-jack (functional in both normal and standby modes)
PHYSICAL SPECIFICATIONS
Security Kensington® Lock Port and keypad lock
Weight 8.2 lb (3.7 kg)
Dimensions (W x D x H) 12.8" x 4.3" x 10.2" (326 x 109 x 259 mm)
