Plugable's DisplayPort to VGA passive adapter allows you to connect from a Dual-Mode DisplayPort (DP++) output on your laptop, desktop, or tablet to virtually any VGA-enabled display. Passive adapters rely on the DisplayPort source output supporting DP++ in order to pass video signals to a VGA display. Our adapter supports resolutions up to 1920x1200 @ 60Hz refresh rate.

Dual-Mode DisplayPort source ports are often noted with a DP++ symbol next to the port itself. If unsure if your DisplayPort is DP++ capable, please check with your system manufacturer.

Compatibility

• Compatible with laptops, desktops, or tablet PCs that have a Dual-Mode DisplayPort output port (DP++) to add a VGA-capable monitor, TV, or projector.
• Compliant with VESA Dual-Mode DisplayPort 1.1.

Applications

• Connect a VGA-equipped monitor to a Dual-Mode DisplayPort (DP++) output from your computer.
• Portable for traveling professionals to connect to other VGA displays.

Non-Compatible Setups

• This adapter is not bi-directional and will not convert video in the other direction.
• Not compatible with Microsoft Surface Docking Stations.
• Does not support AMD Eyefinity or NVIDIA Surround.

In the Bag

• Plugable DisplayPort to VGA Passive Adapter.

Please note that a VGA cable is not included.
