Ruggedness

MIL-STD 810G and IP65 certified Vibration, drop, temperature & humidity resistant
Optional ANSI/ISA 12.12.01

Operating System

Windows® 7 Professional
Windows 8.1 Professional

CPU

Quad-core Intel® Pentium® N3530 2.16 GHz Processor (up to 2.58 GHz) 2MB Cache

Memory

4GB DDR3L

Storage

64GB SSD
Optional 128GB
or 256GB SSD

VGA Controller

Intel HD Graphics

Display

8.1” TFT LCD HD (1280 x 800) 600 NITs LumiBond® 2.0 sunlight readable display with multi-touch technology;
Optional digitizer

Communications

802.11ac WLAN Bluetooth (v4.0 class 1)
Optional GPS
Optional 4G LTE mobile broadband

Camera

HD webcam x 1
8MP rear camera

Power

AC Adapter (65W, 100-240VAC, 50/60Hz)
Li-Ion battery (4200mAH) (up to 8 hours of battery life)

Dimensions and Weight

8.9” x 5.9” x 0.9” (227 x 151 x 24mm)
1.94lbs (0.88kg)

Temperature

Operating Temp: -5.8° F to 122° F / -21°C to 50°C
Storage Temp: -40°F to 160°F / -40°C to 71°C
Humidity: 95% RH, non-condensing

I/O Interfaces

DC in x 1
USB 3.0 x 1
Docking port x 1
Headphone out/Mic-in Combo x 1
Micro HDMI x 1
Optional RF antenna pass-through for GPS,
WLAN and WWAN

Expansion Slot

Optional 1D/2D imager barcode reader,
or Optional 10/100/1000 base-T Ethernet,
or Optional Serial port (RS232),
or Optional MicroSD

SnapBack Add-ons

External battery (2100mAh)
SmartCard
RFID reader SmartCard
Magnetic Stripe Card reader

Warranty

3 Year bumper-to-bumper warranty standard
