• CPU

  Intel® Socket 1151 for 8^th Generation Core^™ Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * Refer to www.asus.com for CPU support list

• Chipset

  Intel® Z370

• Memory

  4 x DIMM, Max. 64GB, DDR4 4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * The maximum memory frequency supported varies by processor.

• Graphic

  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DVI-D ports
  - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 1024 MB

• Multi-GPU Support

  Supports AMD CrossFireX™ Technology

• Expansion Slots

  1 x PCIe 3.0/2.0 x16 (x16, x8/x4+x4) *
  1 x PCIe 3.0/2.0 x16 (max at x4 mode)
  4 x PCIe 3.0/2.0 x1
  *For 3 SSD on CPU support, install a Hyper M.2 X16 card (sold separately) into the PCIeX16_1 slot, enable this card under BIOS settings.

• Storage

  Intel® Z370 Chipset :
  2 x M.2 Socket 3*¹, , with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
  4 x SATA 6Gb/s port(s), gray
  Support Raid 0, 1, 5, 10
  Intel® Optane™ Memory Ready

• LAN

  Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
  ASUS LAN Guard

• Audio

  Realtek® ALC887 8-Channel High Definition Audio CODEC
  - Supports : Jack-detection, Front Panel Jack-retasking
  Audio Feature :
  - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
  - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity

• USB Ports

  Intel® Z370 Chipset :
  8 x USB 3.1 Gen 1 port(s) (4 at back panel, +blue)
  Intel® Z370 Chipset :
  6 x USB 2.0 port(s) (2 at back panel, )

• Special Features

  ASUS 5X Protection III :
  - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
  - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
  - ASUS Overvoltage Protection: World-class circuit-protecting power design
  - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
  - ASUS DIGI+ VRM: 6 Phase digital power design
  ASUS EPU :
  - EPU
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  ASUS Quiet Thermal Solution :
  - Stylish Fanless Design Heat-sink solution & MOS Heatsink
  - ASUS Fan Xpert 4 Core
  ASUS EZ DIY :
  - ASUS O.C. Tuner
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  ASUS Q-Design :
  - ASUS Q-Slot
  - ASUS Q-DIMM
  Overclocking Protection :
  - ASUS C.P.R.(CPU Parameter Recall)
  M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)

• Back I/O Ports

  1 x PS/2 keyboard/mouse combo port(s)
  1 x DVI-D
  1 x HDMI
  1 x LAN (RJ45) port(s)
  4 x USB 3.1 Gen 1 (blue) Type-A
  2 x USB 2.0
  3 x Audio jack(s)

• Internal I/O Ports

  2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) (19-pin)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  2 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
  1 x COM port(s) connector(s)
  4 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  2 x Chassis Fan connector(s) (2 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
  1 x AIO PUMP Header

• Accessories

  User's manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x M.2 Screw Package
  1 x SCD

• BIOS

  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information

• Manageability

  WfM 2.0, DMI 3.0, WOL by PME, PXE

• Support Disc

  Drivers
  ASUS Utilities
  ASUS EZ Update
  Anti-virus software (OEM version)

• Operating System

  Windows® 10 64-bit

• Form Factor

  ATX Form Factor
  12.0 inch x 8.9 inch ( 30.5 cm x 22.6 cm )

• Note

  *1. When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot be used.
