INPUTS

• 1 UXGA on a 15–pin HD (F) connector
• 1 unbalanced stereo audio on a 3.5mm mini jack
• 1 12V DC power on 2–pin spring–loaded terminal block

OUTPUTS

• 1 balanced and 1 unbalanced audio on an 8–pin spring–loaded terminal block
• 1 RGBHV component video on a 9–pin spring–loaded terminal block or on 5 BNC cables

MAX. OUTOUT LEVEL

• Video: 1.7Vpp
• Audio: 8.5Vpp unbalanced, 16.6Vpp balanced

BANDWIDTH (-3DB)

• Video: 380MHz
• Audio: >20kHz

DIFF. GAIN

• 0.08%

DIFF. PHASE

• 0.05Deg

K-FACTOR

• 0.2%

S/N RATIO

• Video: 68dB @5MHz
• Audio: 87dB unbalanced, 85dB balanced

CROSSTALK (ALL HOSTILE)

• Audio: — 51dB (from video)

CONTROLS

• 0 to 10dB equalization @50MHz

COUPLING

• Video: DC
• Audio: Input AC, Output DC

AUDIO THD + NOISE

• 0.01%

AUDIO 2ND HARMONIC

• Unbalanced 0.003%, balanced 0.001%

POWER CONSUMPTION

• 12V DC 80mA

INCLUDED ACCESSORIES

• Power supply

OPTIONS

• RK–2WP 19" rack adapter
