TECHNICAL SPECIFICATIONS

INPUTS:
1 TP on a 2pin large terminal block

OUTPUTS:
1 TP on a 2pin Molex connector

PORTS:
1 bidirectional RS232 serial port on a 3pin terminal block (for use of Kramer service personnel only), 1 USB for firmware upgrades

POWER OUTPUT:
25W

AUDIO BANDWIDTH:
75 to 20kHz @–3dB

S/N RATIO:
84dB unweighted

TOTAL GAIN:
–80dB to +24dB

RS-232 BAUD RATE:
115200bps, fullduplex

PRODUCT DIMENSION:
18.30cm x 17.20cm x 24.40cm (7.20" x 6.77" x 9.61" ) W, D, H

PRODUCT WEIGHT:
4.7kg (10.4lbs) approx

SHIPPING DIMENSION:
44.00cm x 31.00cm x 31.50cm (17.32" x 12.20" x 12.40" ) W, D, H

SHIPPING WEIGHT:
6.0kg (13.2lbs) approx

POWER CONSUMPTION:
24V DC, 1.2A

TRANSMISSION DISTANCE:
8 speakers each up to 30m (100ft) apart

OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:
–40° to +70°C (–40° to 158°F)

HUMIDITY:
10% to 90%, RHL noncondensing

VIBRATION:
ISTA 1A in carton (International Safe Transit Association)

SAFETY REGULATORY COMPLIANCE:
CE

EMI/EMC REGULATORY COMPLIANCE:
CE, Ctick, FCC Class A, ICES, KCC, VCCI

ENVIRONMENTAL REGULATORY COMPLIANCE:
RoHs and WEEE

INCLUDED ACCESSORIES:
1 ferrite ring PN 2582000022

OPTIONS:
Kramer BC2S 300m cable
