TECHNICAL SPECIFICATIONS

INPUTS:
1 TP on a 2pin Large terminal block

OUTPUTS:
2 TP on 2pin Molex connectors

PORTS:
1 bidirectional RS232 serial port on a 3 pin terminal block

BANDWIDTH:
020kHz @–3dB

S/N RATIO:
84dB unweighted

TND+N:
0.02% unweighted

TOTAL GAIN:
Analog/analog: 0dB; analog/SPDIF: –12dBFS

RS-232 BAUD RATE:
115200bps, fullduplex

POWER AMPLIFIER:
Builtin, 2x25W

POWER CONSUMPTION:
24V DC 1.5mA

TRANSMISSION DISTANCE:
Up to 30m (100ft) on a single power supply

PRODUCT DIMENSION:
18.30cm x 17.20cm x 24.40cm (7.20" x 6.77" x 9.61" ) W, D, H

PRODUCT WEIGHT:
2.3kg (5.1lbs) approx

SHIPPING DIMENSION:
44.00cm x 31.00cm x 31.50cm (17.32" x 12.20" x 12.40" ) W, D, H

SHIPPING WEIGHT:
4.5kg (9.9lbs) approx

OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:
–40° to +70°C (–40° to 158°F)

HUMIDITY:
10% to 90%, RHL noncondensing

VIBRATION:
ISTA 1A in carton (International Safe Transit Association)

SAFETY REGULATORY COMPLIANCE:
CE

ENVIRONMENTAL REGULATORY COMPLIANCE:
Complies with appropriate requirements of RoHs and WEEE

INCLUDED ACCESSORIES:
Power supply

OPTIONS:
Kramer BC2S 300m cable
