CONDUCTORS

• Size: 4x2x23AWG
• Material: Annealed copper
• Diameter: 0.56mm ±0.01mm

INSULATION

• Material: Skin/Foam/Skin HDPE
• Diameter: 1.33mm ±0.10mm
• Color Code: White/Blue, White/Orange, White/Green, White/Brown

SCREENING

• Material: Alu/PET per pair (Alu side out)

DRAIN WIRE

• Material: Tinned copper
• Diameter: 0.4mm ±0.01mm

JACKET

• Material: LSHF
• Color: Blue RAL 5012
• Thickness: ≥0.5mm
• Diameter: 7.2mm ±0.2mm

ELECTRICAL

• Impedance: 1–100MHz: 100Ω ±15Ω, 100–250MHz: 100Ω ±20Ω, 250–500MHz: 100Ω ±25Ω
• Propagation Velocity (NVP): 76%
• Voltage Rating: 30V
• Delay Skew: <45ns
• Mutual Pair Capacitance: ≤42pF/m
• Capacitance Unbanlance Pair/ground: ≤1500pF/km
• Conductor DC Resistance: <79.8Ω/km
• Pair Resistance Unbalance DC: <1.5%
• Dielectric Strength: 2.5kV DC (2s)
• Insulation Resistance (500V): >5000MΩ/km

USAGE AND ENVIRONMENTAL

• Storage / Transport / Installation Temperature: 0˚C to +50˚C
• Operation Temperature: –20˚C to +60˚C

MECHANICAL

• Maximum Pulling Tension: : 100N
• Bending Radius - Installed: 50mm
• Bending Radius - During Installation: 60mm

STANDARDS COMPLIANCE - EC VERIFIED

• Electrical: EIA/TIA 568A, ISO/IEC 11801
• Fire Performance: IEC 60332‑1
• Smoke Density: IEC 61034
• Halogen Free: IEC 60754
• RoHS: 2011/65/EU
