Rack PDU, Switched, 1U, 12A/208V, 10A/230V, (8)C13

The APC by Schneider Electric Switched Rack Power Distribution Unit (PDU) distributes power to devices in the rack. It has a sensor that measures the current that it and its attached devices use. It can be monitored through Web, Telnet, SNMP, SSH, or StruxureWare Data Center Expert ® interfaces.

Inlet: The Rack PDU has an IEC-320-C14 inlet on the front of the unit to connect to the power cord.

Outlets: The outlets connect the Rack PDU to equipment in your rack or enclosure. Each outlet allows independent control of the connected equipment and the Rack PDU firmware also provides Outlet User accounts. The Rack PDU has eight IEC-320-C13 outlets.

Digital display: A digital display shows aggregate current being used.

Power cord: The power cord connects the Rack PDU to one power source. The cord connects to the front of the Rack PDU for easier mounting and user access. The 8 ft (2.4 m) cord terminates with a C14 plug.

Manufacturer Part Number
AP7920B
EAN/UPC
0731304331612,731304331612
Full Product Specifications

Note:

  • The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
  • These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
  • These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.

Output

  • Nominal Output Voltage

    208V , 230V
  • Maximum Total Current Draw

    10
  • Output Connections

    (8) IEC 320 C13 (Battery Backup)

  • Different voltages and corresponding amperages

    10A @ 230V, 12A @ 208VA
Input
  • Nominal Input Voltage

    200V , 208V , 230V
  • Input frequency

    50/60 Hz
  • Input Connections

    IEC-320 C14
  • Cord Length

    6.5ft ( 1.98meters )
  • Acceptable Input Voltage

    200-240VAC
  • Number of Power Cords

    1
  • Load Capacity

    2300VA
  • Maximum Input Current

    15A
  • Regulatory Derated Input Current (North America)

    12A
Physical
  • Maximum Height

    1.73inches ( 44mm , 4.4cm )
  • Maximum Width

    17.5inches ( 445mm , 44.5cm )
  • Maximum Depth

    4.25inches ( 108mm , 10.8cm )
  • Rack Height

    1U
  • Net Weight

    5.0lbs. ( 2.27kg )
  • Shipping weight

    7.6lbs. ( 3.45kg )
  • Shipping Height

    2.75inches ( 70mm , 7.0cm )
  • Shipping Width

    18.5inches ( 470mm , 47.0cm )
  • Shipping Depth

    13.5inches ( 343mm , 34.3cm )
  • Color

    Black
Environmental
  • Operating Environment

    32 - 113 °F ( 0 - 45 °C )
  • Operating Relative Humidity

    0 - 95 %
  • Operating Elevation

    0-10000ft ( 0-3000meters )
  • Storage Temperature

    -25 - 65 °C
  • Storage Relative Humidity

    0 - 95 %
  • Storage Elevation

    0-50000ft ( 0-15000meters )
Conformance
  • Approvals

    cUL Listed, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, UL 60950, UL Listed, VDE
  • Standard warranty

    2 years repair or replace
Sustainable Offer Status
  • RoHS

    Compliant
  • REACH

    REACH: Contains No SVHCs
  • Battery Directive

    Compliant
  • Battery Notes

    ts_Battery_Notes
