The APC by Schneider Electric Switched Rack Power Distribution Unit (PDU) distributes power to devices in the rack. It can be monitored through Web, Telnet, SNMP, SSH, StruxureWare Data Center Expert® interfaces.
Outlets: The outlets connect the Rack PDU to equipment in your rack or enclosure. Each outletallows independent control of the connected equipment and the Rack PDU firmware also provides Outlet User accounts. The PDU has eight IEC-320-C13 outlets.
Power cord: The Rack PDU has an IEC-320-C20 inlet on the front of the unit to connect to the power cord. The power cord connects the Rack PDU to one power source. The cord connects to the front of the Rack PDU for easier mounting and user access. The 8 foot (2.4 meter) cord terminates with a C20 plug.
Digital display: The digital display shows the aggregate current being used by th
Note:
- The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
- These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
- These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.
Output
-
Nominal Output Voltage
208V , 230V -
Maximum Total Current Draw
16 -
Output Connections
(8) IEC 320 C13 (Battery Backup)
-
Nominal Input Voltage
200V , 208V , 230V -
Input frequency
50/60 Hz -
Input Connections
IEC-320 C20 -
Cord Length
8.2ft ( 2.5meters ) -
Acceptable Input Voltage
200-240VAC -
Number of Power Cords
1 -
Load Capacity
3680VA -
Maximum Input Current
20A -
Regulatory Derated Input Current (North America)
16A
-
Maximum Height
1.73inches ( 44mm , 4.4cm ) -
Maximum Width
17.5inches ( 445mm , 44.5cm ) -
Maximum Depth
4.25inches ( 108mm , 10.8cm ) -
Rack Height
1U -
Net Weight
5.0lbs. ( 2.27kg ) -
Shipping weight
7.6lbs. ( 3.45kg ) -
Shipping Height
2.75inches ( 70mm , 7.0cm ) -
Shipping Width
18.5inches ( 470mm , 47.0cm ) -
Shipping Depth
13.5inches ( 343mm , 34.3cm ) -
Color
Black
-
Operating Environment
32 - 113 °F ( 0 - 45 °C ) -
Operating Relative Humidity
0 - 95 % -
Operating Elevation
0-10000ft ( 0-3000meters ) -
Storage Temperature
-25 - 65 °C -
Storage Relative Humidity
0 - 95 % -
Storage Elevation
0-50000ft ( 0-15000meters )
-
Approvals
cUL Listed, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, MIC, UL 60950, UL Listed, VDE, VCCI -
Standard warranty
2 years repair or replace
-
RoHS
Compliant -
REACH
REACH: Contains No SVHCs -
Battery Directive
Compliant -
Battery Notes
ts_Battery_Notes
