INPUT

• 1 UXGA on a 15–pin HD connector

OUTPUTS

• 2 UXGA on 15–pin HD connectors

BANDWIDTH (-3DB)

• 370MHz

DIFF. GAIN

• 0.03%

DIFF. PHASE

• 0.03Deg

K-FACTOR

• <0.05%

S/N RATIO

• 71dB

COUPLING

• DC

INDICATOR

• Power LED

POWER CONSUMPTION

• 5V DC, 76mA

INCLUDED ACCESSORIES

• Power supply, mounting bracket

OPTIONS

• RK–3T 19" rack adapter

PRODUCT DIMENSION

• 12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H

PRODUCT WEIGHT

• 0.2kg (0.4lbs) approx

SHIPPING DIMENSION

• 20.00cm x 6.00cm x 20.50cm (7.87" x 2.36" x 8.07" ) W, D, H

SHIPPING WEIGHT

• 0.7kg (1.5lbs) approx
