INPUT

• 1 HDMI on an HDMI connector

OUTPUT

• 1 HDMI on an HDMI connector

BANDWIDTH

• Supports up to 17.82Gbps (5.94Gbps per graphic channel)
• supports up to 4K @60Hz (4:2:0) including WUXGA and 1080p 36–bit Deep Color

COMPLIANCE WITH HDMI STANDARD

• HDMI 2.0, HDCP

INDICATOR LED

• ON

POWER SOURCE

• 5V DC, 230mA

OPERATING TEMPERATURE

• 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE

• –40° to +70°C (–40° to 158°F)

HUMIDITY

• 10% to 90%, RHL non–condensing

COOLING

• Convection

ENCLOSURE TYPE

• Aluminium

RACK MOUNT

• With optional adapter

FURNITURE MOUNT

• With included rubber feet

VIBRATION

• ISTA 1A in carton (International Safe Transit Association)

REGULATORY COMPLIANCE

• CE

ENVIRONMENTAL REGULATORY COMPLIANCE

• Complies with appropriate requirements of RoHs and WEEE

INCLUDED ACCESSORIES

• Power supply

OPTIONS

• RK–4PT 19” rack adapter

WARRANTY

• 7 years parts and labor

PRODUCT DIMENSION

• 6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96" ) W, D, H

PRODUCT WEIGHT

• 0.1kg (0.2lbs) approx

SHIPPING DIMENSION

• 15.70cm x 12.00cm x 8.70cm (6.18" x 4.72" x 3.43" ) W, D, H

SHIPPING WEIGHT

• 0.5kg (1.1lbs) approx
