Output

• Output power capacity

  2.7 KWatts / 3.0 kVA

• Max Configurable Power (Watts)

  2.7 KWatts / 3.0 kVA

• Nominal Output Voltage

  120V

• Output Voltage Distortion

  Less than 2%

• Output Frequency (sync to mains)

  50/60Hz +/- 3 Hz

• Load Crest Factor

  3 : 1

• Topology

  Double Conversion Online

• Waveform type

  Sine wave

• Output Connections

  (8) NEMA 5-20R (Battery Backup)

  (1) NEMA L5-20R (Battery Backup)

• Bypass

  Internal Bypass (Automatic and Manual)

Input

• Nominal Input Voltage

  120V

• Input frequency

  40 - 70 Hz (auto sensing)

• Input Connections

  NEMA L5-30P

• Cord Length

  8ft ( 2.44meters )

• Number of Power Cords

  1

Batteries & Runtime

• Battery type

  Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

• Included Battery Modules

  1

• Typical recharge time

  3hour(s)

• Replacement Battery

  APCRBC152

• Expected Battery Life (years)

  3 - 5

• RBC Quantity

  1

• Extendable Run Time

  1

• Battery Volt-Amp-Hour Capacity

  454

• Extended Run Options

  APC-Smart-UPS-SRT-3000VA-RM-120V-Network-Card

• Runtime

  View Runtime Graph

  View Runtime Chart

• Efficiency

  View Efficiency Graph

Communications & Management

• Interface Port(s)

  RJ-45 10/100 Base-T , RJ-45 Serial , Smart-Slot , USB

• Pre-Installed SmartSlot™ Cards

  AP9631

• Control panel

  Multi-function LCD status and control console

• Audible Alarm

  Audible and visible alarms prioritized by severity

• Emergency Power Off (EPO)

  Yes

Surge Protection and Filtering

• Surge energy rating

  340Joules

• Filtering

  --

Physical

• Maximum Height

  3.35inches ( 85mm , 8.5cm )

• Maximum Width

  17.0inches ( 432mm , 43.2cm )

• Maximum Depth

  25.0inches ( 635mm , 63.5cm )

• Rack Height

  2U

• Net Weight

  69.0lbs. ( 31.3kg )

• Shipping weight

  88.0lbs. ( 39.92kg )

• Shipping Height

  9.7inches ( 246mm , 24.6cm )

• Shipping Width

  23.6inches ( 599mm , 59.9cm )

• Shipping Depth

  34.3inches ( 871mm , 87.1cm )

• Color

  Black

• Units per Pallet

  6.0

Environmental

• Operating Environment

  32 - 104 °F ( 0 - 40 °C )

• Operating Relative Humidity

  0 - 95% non-condensing %

• Operating Elevation

  0-10000ft ( 0-3000meters )

• Storage Temperature

  -15 - 45 °C

• Storage Relative Humidity

  0 - 95% non-condensing %

• Storage Elevation

  0-50000ft ( 0-15000meters )

• Audible noise at 1 meter from surface of unit

  55.0dBA

• Protection Class

  IP 20

Conformance

• Approvals

  CSA C22.2 No.107.3-05, ENERGY STAR (USA), FCC Part 15 Class A, OSHPD, UL 1778

• Standard warranty

  3 years repair or replace (excluding battery) and 2 years for battery

Sustainable Offer Status

• RoHS

  Compliant

• REACH

  REACH: Contains No SVHCs
