RackStation RS3617xs SAN/NAS Server

High-performance NAS server

RS3617xs delivers high performance at over 3,263 MB/s sequential throughput and 333,941 IOPS under a RAID 5 configuration with 10GbE Link Aggregation. Equipped with 4GB DDR3 ECC RAM (upgradeable to 32GB), RS3617xs ensures data accuracy when handling high-value data and mission-critical tasks across large-scale businesses.

Scale on demand

As your data storage needs grow, RS3617xs can be connected to a dedicated RX1217/RX1217RP expansion unit, allowing you to expand storage capacity up to 36 drives without disrupting service. The high-bandwidth expansion cable ensures speedy data transmission between the main server and expansion unit.

10GbE network capability

In addition to the default four Gigabit ports, RS3617xs comes with dual PCIe 3.0 x8 slots that supports up to two 10GbE Network Interface Cards (NIC), maximizing bandwidth and meeting high performance requirements for data-intensive applications.

Reliable redundancy mechanisms

RS3617xs comes with comprehensive redundancy mechanisms to ensure business continuity. Built-in four LAN ports with failover provides the reliable redundancy in the event of unexpected network failure. The high reliability system design including fan-less CPU heat-sink and passive cooling technologies prevents single point of failure.

Hardware encryption engine enhances file transfer speeds

RS3617xs is equipped with an encryption engine which offloads encryption calculation tasks away from the main CPU. Thus, the CPU can be free for other important tasks. In addition, Advanced Encryption Standard (AES) on shared folders with hardware acceleration ensures security without compromising access performance, providing over 2,612MB/s in reading.

SSD cache technology

RS3617xs enables the combination of hard drives and read/write-optimized SSD cache, boosting throughput efficiently while minimizing cost per gigabyte. With full SSD cache reading and writing support, RS3617xs offers a significant reduction in I/O latency without crippling your budget. With only a small upfront investment, businesses can benefit from significant server performance enhancement.

5 year warranty

Synology RS3617xs is backed with Synology's 5-year limited warranty. With technical support and hardware replacement service, the five-year warranty maximizes your enterprises' return on investment. For the entire duration, you will enjoy technical support via e-mail and telephone.

Synology Replacement Service (SRS)

The Synology Replacement Service (SRS) provides free shipment of replacement units as early as the next business day. SRS can expedite the process of replacing defective products and minimize service downtime.

Award winning OS - DiskStation Manager

Synology DiskStation Manager (DSM) is a sleek, browser-based operating system running on every DiskStation and RackStation, which makes managing your Synology NAS a breeze. Featuring an intuitive user interface, DSM makes accessing and sharing your data smarter and simpler. Synology's Package Center lets you download and install useful add-on packages designed specifically for individual or business needs, meaning you can enjoy more entertainment in your life or better productivity at work.

Manufacturer Part Number
RS3617XS
EAN/UPC
0846504002214,846504002214,4711174722211
Full Product Specifications

Note:

  • The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
  • These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
  • These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.

Hardware Specifications

CPU
CPU Model: Intel Xeon E3-1230 v2
CPU Architecture: 64-bit
CPU Frequency: Quad Core 3.3 GHz
Hardware Encryption Engine (AES-NI): Yes

Memory
System Memory: 4 GB DDR3 ECC
Memory Module Pre-installed: 2 GB x 2
Total Memory Slots: 4
Memory Expandable up to: 32 GB (8 GB X 4)
Storage
Drive Bay(s): 12
Maximum Drive Bays with Expansion Unit: 36
Compatible Drive Type (See all supported drives):

  • 3.5" SATA III / SATA II HDD
  • 2.5" SATA III / SATA II HDD
  • 2.5" SATA III / SATA II SSD

Maximum Internal Raw Capacity: 96 TB (8 TB HDD x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units: 288 TB (8 TB HDD x 36) (Capacity may vary by RAID types)
Maximum Single Volume Size:
  • 200 TB (32GB RAM required, for RAID 5 or RAID 6 groups only)
  • 108 TB

Hot Swappable Drive: Yes

Notes:
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size doesn't equal to the maximum raw capacity, which is limited by the aggregated space of installed drives.

External Ports
USB 2.0 Port: 2
USB 3.0 Port: 2
Expansion Port: 2
File System
Internal Drives:
  • Btrfs
  • EXT4

External Drives:
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*

Appearance
Size (Height x Width x Depth): 88 mm x 445 mm x 570 mm

Weight: 13.3 kg

Others
RJ-45 1GbE LAN Port: 4 (with Link Aggregation / Failover support)
Wake on LAN/WAN: Yes

PCIe Slot for Network Card (See more) : 2 (white at x8 mode, black at x4 mode)
System Fan: 80 mm x 80 mm x 4 pcs
Fan Speed Mode:
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode

Easy Replacement System Fan: Yes

Wireless Support (dongle): Yes

Power Recovery: Yes

Noise Level*: 40.5 dB(A)

Scheduled Power On/Off: Yes

Power Supply Unit / Adapter: 500W

AC Input Power Voltage: 100V to 240V AC
Power Frequency: 50/60 Hz, Single Phase
Power Consumption*: 116.7 W (Access)
60.3 W (HDD Hibernation)

British Thermal Unit: 398.19 BTU/hr (Access)
205.75 BTU/hr (HDD Hibernation)

Environment Temperature
Operating Temperature: 5°C to 35°C (40°F to 95°F)
Storage Temperature: -20°C to 60°C (-5°F to 140°F)
Relative Humidity: 5% to 95% RH
Certification:
  • FCC Class A
  • CE Class A
  • BSMI Class A

Warranty: 5 Years
Notes:
  • Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
  • exFAT Access is purchased separately in Package Center.
