Intel Omni-Path Architecture 100Gb 48-port Managed Switch 829911-B21

I/O ports and slots: 48 QSFP28 ports

Additional ports and slots (Managed switch only):

• 10/100/1000 Base-T Ethernet port
• 1 USB port

Power supplies: 2 power supplies (1+1 redundant )

Fan units: 6 Fans (N+1 redundant)

Physical characteristics

Dimensions 1.72 in (H) x 17.3 in (W) x 16.8 in (D) 4.32 cm (H) x 43.96 cm (W) x 42.67 cm (D)

Weight 7.01 kg (Managed) 15.45 lb (Managed)

Management processor (Managed Switch only): Q7 Intel® Atom™ processor

Performance

Latency ≤110 ns port-to-port
Throughput up to 9.6 Tbps
Maximum multicast table size 8192 entries
Maximum unicast table size 49151 entries

Environment

Operating temperature 5°C to 40°C (41°F to 104°F)
Storage temperature -40°C to 70°C
Operating humidity 10% to 85%
Operating Altitude 0 to 3048m (0 to 10,000 feet)
Acoustic Less than 7.0 Bels (70 dB)
Airflow 70 CFM

Electrical characteristics

Frequency 50/60 Hz
Voltage 100 - 240 VAC
Maximum power rating 238W

Safety

US/Canada

• TUV NRTL: UL 60950-1, CSA 22.1.No. 60950-1

Europe

• TUV: EN60950-1

International

• CB Scheme: IEC 60950-1

Customs Union: Russian Federation, Belarus and Kazakhstan

• TR CU 004/2011 “On Safety of Low-Voltage Equipment”

Emissions

US/Canada

• FCC Part 15, Subpart B, Class A
• CAN ICES-3 (A)/NMB-3(A)

Europe/International

• CISPR22
• CISPR32/EN55032
• EN55024
• EN61000-3-2
• EN61000-3-3

Japan

• VCCI, Class A

Australia/New Zealand

• AS/NZS CISPR 22, Class A

Korea

• RRA/KC (KN32, KN35), Class A

Taiwan

• BSMI (CNS 13438), Class A

Customs Union: Russian Federation, Belarus and Kazakhstan

• TR CU 020/2011 "Electromagnetic compatibility of technical equipment”

RoHS/REACH

• Complies with RoHS II Directive 2011/65/EU of the European Parliament
• Complies with REACH Regulation (EC) No 1907/2006
