Note:

• The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
• These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
• These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.

Electrical
Input connection IEC-309 32 A cord included
Acceptable input 200–240 VAC +6% to -10%
voltage
Maximum input current 32 A
(phase)
Input frequency 50/60 Hz
Output voltage 200–240 VAC +6% to -10%
Output connections (4) C19
Maximum output C19; 16 A
current (outlet)
Maximum output 32 A
current (phase)
Maximum output 16 A
current (bank)
Overcurrent protection (2) 20 A, 1-pole breakers
(internal)
Cord length 3.65 m (12.00 ft)

Physical
Dimensions 43.81 x 4.36 x 9.29 cm
(H x W x D) (17.25 x 1.72 x 3.66 in)
Shipping dimensions 47.80 x 20.80 x 18.00 cm
(H x W x D) (18.82 x 8.19 x 7.09 in)
Weight 2.78 kg (6.12 lb)
Shipping weight 3.75 kg (8.25 lb)

Environmental
Maximum elevation 0 to 3048 m (0 to 10,000 ft)
(above MSL) 0 to 15 240 m (0 to 50,000 ft)
Operating
Storage
Temperature 0 to 50°C (32 to 122°F)
Operating –15 to 60°C (5 to 140°F)
Storage
Humidity 5 to 95%, non-condensing
Operating 5 to 95%, non-condensing
Storage

Compliance
Safety approvals VDE, CE
ROHS 2011/65/EU–latest revision
