General

Nominal Output Voltage (Vdc) 240

Rated Output Current (A) 47

Battery

Battery Quantity (pcs) 40

Single Battery Voltage (V) 12

Single Battery Capacity (AH) 9

Built-in ChargerNo

Typical Recharge Time (Hours) 5

User ReplaceableNo

Expansion Ready (Daisy-chain)Yes

Physical

Form FactorTower

Enclosure ConstructionMetal

ColorBlack

Physical Size

Dimensions (WxHxD) (in.)10.24 x 28.27 x 21.65

Dimensions (WxHxD) (mm.)260 x 718 x 550

Weight (lbs.)255.7

Weight (kg.)116

Shipping Dimensions

Dimensions (WxHxD) (in.)16.85 x 38.19 x 28.35

Dimensions (WxHxD) (mm.)428 x 970 x 720

Weight (lbs.)277.8

Weight (kg.)126

Environmental

Operating Temperature (°F)32 ~ 104

Operating Temperature (°C)0 ~ 40

Operating Relative Humidity (Non-condensing) (%) 0 ~ 90

Operating Elevation (feet/meters) 0-5,000 feet (0-1,500 meters)

Storage Temperature (°F)-4 ~ 104

Storage Temperature (°C)-20 ~ 40

Storage Relative Humidity (Non-condensing) (%) 0 ~ 90

Storage Elevation (feet/meters) 0-5,000 feet (0-1,500 meters)

Certifications

Certifications: CE

RoHS: Yes
