DRAM: DDR2 64MByte

FLASH: 8MByte

Port: 10/100Mbps LAN*2

Speed:

• 11b:11M, 5.5M, 2M, 1Mbps
• 11g:54M, 48M, 36M, 24M, 18M, 12M, 9M, 6Mbps
• 11n:6.5M, 13M, 13.5M, 19.5M, 26M, 27M, 39M, 40.5M, 52M, 54M, 58.5M, 65M, 81M, 108M, 121.5M, 135M, 150M, 270M, 300Mbps

Transmission: DSSS

Modulation: OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK

Standards:

• IEEE802.11n, IEEE802.11g, IEEE802.11b,
• IEEE802.3u, IEEE802.3af

Protocol:

• CSMA/CA, TCP/IP, IPX/SPX, NetBEUI, DHCP,
• NDIS3, NDIS4, NDIS5

RF@25±2dB:

• 802.11b I 27±2dBm
• 802.11g
• 6-24Mbps I 26±2dB
• 36-48Mbps I 25±2dB
• 54Mbps I 24±2dB
• 802.11n
• „HT20
• MCS 7 I 24.5±2dB
• „HT40
• MCS 7 I 24±2dB

Sensitivity:

• IEEE 802.11b I 11Mbps ≤ -85dBm
• IEEE 802.11g I 54Mbps ≤ -73
• 802.11n„
• HT20 I MCS 0 ≤ -86; MCS 7 ≤ -65
• „HT40 I MCS 0 ≤ -83; MCS 7 ≤ -62

Antenna:

• Frequency I 2300~2800MHz
• Direction I Horizontal/Vertical
• Gain I 16DBi

Management:

• WEP management I Yes
• SNMP MIB I Yes
• Telnet I Yes
• Serial I Yes

Security:

• MAC address control I Yes
• Encryption I WEP 64/128bits,WPA,WPA2,802.1x

Opertating conditions:

• Working temperature I -22F~149F
• Storage temperature I -58F~176F
• Humidity (non-condensed) I ≤95% (NA)
