General

Nominal Output Voltage (Vdc): 72

Rated Output Current (A): 60

Battery

Battery Type: Sealed Lead-Acid

Supplier Battery Model: HRC1234W

Battery Quantity (pcs):  12

Single Battery Voltage (V): 12

Single Battery Capacity (AH): 9

Built-in Charger: No

User Replaceable: Yes

Hot-Swappable: Yes

Expansion Ready (Daisy-chain): Yes

Replacement Battery Pack: RBP0077

Replacement Battery Pack Quantity (pcs): 2

Physical

Form Factor: Rack/Tower

Enclosure Construction: Metal

Color: Black

Rackmount Rail: Yes

Rackmount Ears: Yes

Physical Size

Dimensions (WxHxD) (mm.): 433 x 88 x 600

Weight (kg.): 44

Installed Rack Height (U): 2

Shipping Dimensions

Dimensions (WxHxD) (mm.): 565 x 240 x 880

Weight (kg.): 52.7

Environmental

Operating Temperature (°C): 0 ~ 40

Operating Relative Humidity (Non-condensing) (%):  0 ~ 90

Operating Elevation (feet/meters): 0-10,000 feet (0-3,000 meters)

Storage Temperature (°C): -15 ~ 45

Storage Relative Humidity (Non-condensing) (%):  0 ~ 95

Storage Elevation (feet/meters): 0-50,000 feet (0-15,000 meters)

Certifications

Certifications: CE, C-Tick

RoHS: Yes

WARRANTY

Product Warranty Period (Year): 2

Battery Warranty Period (Year): 2

Connected Equipment Guarantee: 100,000 USD ; 3 years
