RV132W Wireless Router

The Cisco® RV132W Wireless-N ADSL2+ VPN Router is easy to use, set up, and deploy. This flexible router offers great performance and is suited for small or home offices (SOHO) and smaller deployments.

This networking-in-a-box model offers a quick deployment process that only takes a few minutes to set up using a web-based user interface.

Features:

  • VPN security
  • Built-in three-port Fast Ethernet switch
  • Asymetrical Digital Subscriber Line 2 plus (ADSL2+) connectivity
  • Fast Ethernet WAN
  • USB 3G/4G/LTE
  • Limited lifetime warranty
  • Industry-leading support
  • Internal antennas
  • Sleek new design

The RV132W can be used to connect to an ADSL2+ interface or a regular Ethernet WAN interface. The model supports the free Cisco Small Business FindIT Network Discovery Utility, which allows for automatic discovery and one-click software downloads.

Manufacturer Part Number
RV132W-A-K9-NA
EAN/UPC
0882658800252,882658800252
Full Product Specifications

Note:

  • The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
  • These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
  • These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.

Standards: IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1D, 802.1p, 802.1w (Rapid Spanning Tree), 802.1X (security authentication), 802.1Q (VLAN), 802.11i (Wi-Fi Protected Access [WPA2] security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460), Routing Information Protocol (RIP) v1 (RFC 1058), RIP v2 (RFC 1723)

Ports: LAN, WAN, USB, console

Switch: Power button (on, off)

Buttons: Reset, Wi-Fi on, off

Cabling type: Category 5e or better

LEDs: Power, DSL or WAN, Internet, LAN (ports 1-3), wireless, VPN, USB

Operating system: Linux

Network

Network protocols:
  • Dynamic Host Configuration Protocol (DHCP) server
  • Point-to-Point Protocol over Ethernet (PPPoE)
  • Point-to-Point Tunneling Protocol (PPTP)
  • DNS proxy
  • DHCP relay agent
  • Internet Group Management Protocol (IGMP) proxy and multicast forwarding
  • Rapid Spanning Tree Protocol (RSTP)
  • Dynamic Domain Name System (DynDNS, NOIP)
  • Network Address Translation (NAT), Port Address Translation (PAT)
  • One-to-one NAT
  • Port management
  • Port mirroring
  • Software configurable DMZ to any LAN IP address
  • Session Initiation Protocol (SIP) Application Layer Gateways (ALG)
LAN: 3 10/100-Mbps LAN ports with a managed switch

WAN: 1 10/100-Mbps FE WAN port

WAN: 1 ADSL2+

WLAN: Built-in high-speed 802.11n wireless access point

Routing protocols:
  • Static routing
  • Dynamic routing
  • RIP v1 and v2
  • Inter-VLAN routing
Network Address Translation (NAT): Port Address Translation (PAT), Network Address Port Translation (NAPT) protocol

VLAN support: Port-based and 802.1Q tag-based VLANs

Number of VLANs: 6 active VLANs (2-4094 range)

IPv6:

  • Dual-stack IPv4 and IPv6
  • 6rd
  • Stateless address auto-configuration
  • DHCPv6 server for IPv6 Clients on a LAN
  • DHCPv6 client for WAN connectivity
  • Internet Control Message Protocol (ICMP) v6
  • Static IPv6 routing
  • Dynamic IPv6 routing with RIPng
Network edge (DMZ): Software-configurable to any LAN IP address

Layer 2: 802.1Q-based VLANs, 6 active VLANs

Security

Firewall:

  • Stateful packet inspection (SPI) firewall, port forwarding and triggering, denial-of-service (DoS) prevention, software-based DMZ
  • DoS attacks prevented:
  • SYN Flood
  • Echo Storm
  • ICMP Flood
  • UDP Flood
  • TCP Flood
  • Block Java, cookies, active-X, HTTP proxy
Access control: IP access control lists; MAC-based wireless access control

Content filtering: Static URL blocking or keyword blocking

Secure management: HTTPS, username and password complexity

Wi-Fi Protected Setup (WPS): WPS

User privileges: 2 levels of access: admin and guest

Quality of Service (QoS)

QoS:
  • 802.1p port-based priority on LAN ports, application-based priority on WAN ports
  • 4 queues
  • Differentiated Services Code Point (DSCP) support
  • Class of Service (CoS)
  • Bandwidth management for service prioritization
Performance

NAT throughput: 75 Mbps (Ethernet WAN)

Concurrent sessions: 2000

IPsec VPN throughput (3DES, AES): 3 Mbps

Configuration

Web user interface: Simple, browser-based configuration (HTTP, HTTPS)

Command-line interface (CLI): Command line using SSH

Management

Web user interface: Simple, browser-based configuration (HTTP, HTTPS)

CLI: Command line using SSH

Management protocols: Web browser, Bonjour, Universal Plug and Play (UPnP)

Event logging: Local, syslog, email alerts

Network diagnostics: Ping, Traceroute, DNS lookup, and port mirror

Upgradability: Firmware-upgradable through a web browser, imported or exported configuration file

System time: Supports NTP, daylight savings, manual entry

Languages: GUI supports English

Wireless

Radio and modulation type: 802.11b: direct sequence spread spectrum (DSSS), 802.11g: orthogonal frequency division multiplexing (OFDM), 802.11n: OFDM

WLAN: 2.4 GHz IEEE 802.11n standard-based access point with 802.11b/g compatibility

Operating channels: 11 North America, 13 most of Europe, auto-channels selection

Wireless isolation: Wireless isolation between clients

Internal antennas: 2

Antenna gain in dBi: 3 dBi

Transmit power: 802.11b: 17 dBm +/- 2.5 dBm; 802.11g: 15 dBm +/- 2.5 dBm; 802.11n: 15 dBm +/- 2.5 dBm

Receiver sensitivity: -85 dBm at 11 Mbps, -73 dBm at 54 Mbps, -68 dBm at mcs15, HT20, -65 dBm at mcs15, HT40

Radio frequency: Single-band, works on 2.4 GHz

Active WLAN clients: Supports up to 50 concurrent clients

Multiple SSIDs: Supports multiple Service Set Identifiers (SSIDs), up to 4 separate virtual networks

Wireless VLAN map: Supports SSID to VLAN mapping with wireless client isolation

WLAN security: Wired Equivalent Privacy (WEP), WPA, WPA2-PSK, WPA2-ENT, 802.11i

Wi-Fi Multimedia (WMM): WMM, WMM power save (WMM-PS)

Environmental

Power: 12V 1A

Certifications: FCC, CE, IC, Wi-Fi

Operating temperature: 0° to 40°C (32° to 104°F)

Storage temperature: -20° to 70°C (-4° to 158°F)

Operating humidity: 10% to 85% non-condensing
