Ultra Wi-Fi. Ultra Features. Ultra Connected Experience
The Intel® Dual Band Wireless-AC 8260 is Intel’s 3rd Generation 802.11ac, dual band, 2x2 Wi-Fi + Bluetooth®4.1 adapter. It’s engineered to deliver lower power consumption 1, improved RF coexistence 1, and complete Microsoft Windows 10 support. Combined with Intel ® Core™ processors and exceptional Intel wireless innovations like Intel® Dynamic Regulatory Solution, the Intel® Dual Band Wireless-AC 8260 dramatically reshapes your connected experience at home, work or on the go.
Note:
- The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
- These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
- These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.
General
Dimensions (H x W x D) M.2 2230: 22 mm x 30 mm x 2.4 mm [1.5mm Max (Top Side)/ 0.1mm Max (Bottom Side)] M.2 1216: 12 mm x 16 mm x 1.8 mm
Weight M.2 2230: 2.4g M.2 1216: 0.6g
Antenna Diversity Supported
Radio ON/OFF Control Supported via software
Connector interface M.2: PCIe, USB
Operating Temperature (Adapter Shield) 0º to +80°C
Humidity Non-Operating 50% to 90% RH non-condensing (at temperatures of 25°C to 35°C)
Operating Systems Microsoft Windows 7, Microsoft Windows 8.1, Microsoft Windows Next, Linux (limited feature support)
Wi-Fi Alliance Wi-Fi CERTIFIED for 802.11ac, Wi-Fi CERTIFIED a/b/g, Wi-Fi CERTIFIED n, WMM, WPA, WPA2, and WPS, WPS 2.0, Protected Management Frames, Wi-Fi Direct for peer to peer device connections Wi-Fi Miracast Source
IEEE WLAN Standard IEEE 802.11abgn, 802.11ac, 802.11d, 802.11e, 802.11i, 802.11h , 802.11w
Cisco CCX CCX 4.x/CCX Lite Compliant
Architecture Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes
Roaming Supports seamless roaming between respective access points (802.11b, 802.11g, 802.11a/b/g, 802.11a/b/g/n, and 802.11ac)
Bluetooth® Dual Mode Bluetooth® 2.1, 2.1+EDR, 3.0,4.0, 4.1, BLE, 4.2
Security
Authentication WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA
Authentication Protocols PAP, CHAP, TLS, GTC, MS-CHAP, MS-CHAPv2
Encryption 64-bit and 128-bit WEP, AES-CCMP
Wi-Fi Direct Encryption and Authentication WPA2, AES-CCMP
Product Safety UL, C-UL, CB (IEC 60950-1)
Management Frame Protection 802.11w (WFA-Protected Management Frames)
Compliance
Government FIPS,FISMA
