Full Product Specifications
Note:
- The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
- These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
- These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.
Product Number: AC790S
Network Technology
- 4G CA 1800+700, 1800+2600, 2600+700, 2600+2600 MHz
- 4G 700/900/1800/2100/2600 MHz
- 3G 850/900/1900/2100 MHz
- Wi-Fi 802.11 ac, 2x2 MIMO, simultaneous Dual-Band 2.4GH/5GHz
- Chipset: Qualcomm - MDM9230 (Modem) - WTR3925 (RF) - QCA6174 (Wi-Fi)
Wi-Fi Features
- Wi-Fi 802.11 ac/b/g/n, 2x2 MIMO
- Dual-Band Wi-Fi 2.4GHz/5GHz
- Multiple SSID/Guest Wi-Fi support
- Wi-Fi Protected Setup (WPS)
Device Display
- 2.4” QVGA capacitive LCD touchscreen
SIM
Battery
- Removable lithium-ion (2930 mAh)
- Up to 11 hours of continuous use
- Up to 349 hours on standby
Security
- Wi-Fi security encryption methods:
- WEP 64 (Open/Shared)
- WEP 128 (Open/Shared)
- WPA Personal TKIP
- WPA Personal TKIP AES
- WPA2 Personal AES
- WPA2 Personal TKIP AES
- WPA/WPA2
- Wi-Fi Protected Setup (WPS)
- VPN pass-through
- NAT firewall
- Security web interface
- Multiple SSID/Guest Wi-Fi support
- View & block connected devices from the touchscreen
- Password protected Web UI
- Ability to turn off Wi-Fi or USB Tethering
Dimensions
- 110 mm (L) x 68 mm (W) x 15 mm (H)
Weight
Antennas Diversity Support
- 2X2 MIMO (multiple-input and multiple-output) antenna for LTE
- Dual TS-9 external 4G/3G antenna ports
- 2x2 MIMO antenna for Wi-Fi
Environmental
- Operating temperature: 0 to 35° Celsius
- Storage temperature: -40 to 85° Celsius
- RoHS compliant
Package Contents
- NETGEAR AirCard 790S Mobile Hotspot
- Removable Lithium Ion (Li-ion) battery 2930 mAh
- Quick Start Guide
- Manufacturer’s warranty card
- AC charger and USB charging cable
- Jump boost cable
