Specifications

Protocol standards: IEEE 802.11n ； IEEE 802.11g ； IEEE 802.11b ； IEEE 802.11a ； IEEE 802.11ac

Transmission rate:

• 11b：1/2/5.5/11Mbps
• 11g：6/9/12/18/24/36/48/54Mbps
• 11n：up to 150Mbps
• 11ac：up to 867Mbps

Frequency range:

• 2.412 ~ 2.4835 GHz
• 5.180 ~ 5.320GHz
• 5.500 ~ 5.700GHz
• 5.745 ~ 5.825GHz

Operating Channels:

• 1 ~ 14 （2.4G）
• 36 ~ 165 (5G)

Power Transmission: 18 dBm （Typical）

Spread-spectrum technology: DSSS

Modulation type: CCK / OFDM / BPSK / QPSK / QAM

Receiver Sensitivity:

• 11n： -68dBm@130M ； -68dBm@108M
• 11g： -69dBm@54M
• 11b： -85dBm@11M
• 11ac：-59dBm@867M

Encryption:

• WPA / WPA2 / WPA-WPA2 / 802.1x
• 64 / 128 bit WEP encryption
• WPS (PIN, PBC)

Interface: USB 3.0

Antenna: Built-in omni-directional smart antenna

Housing Material: ABS

Dimensions: 64(W) X 25.5(H) X 8.4(D) mm

Weight:  Approximately 12.8g
