Standard: EIA-RS310D
M/B Form Factor: ATX (12" x 9.6")
Dimensions (D x W x H)
w/o Front Panel: 559 x 482.6 x 133.4 mm
(22" x 19" x 5.25")
Drive Bay:

External: 5.25" x 4 or Hot-Swap 3.5" x 6 or 2.5" x 6, Slim ODD x 1

Internal: 3.5" x 1 or 2.5" x 1

Power Supply: Supports
▪ Form Factor: 2U Single or 2U 1+1 Redundant
▪ Watt: Single 500W, Redundant 500W
Indicator: Power Status, HDD, LAN Activity LEDs
Front Control Panel: Power Switch, System Reset, USB 2.0 x 2
Chassis Security: Intrusion Switch
Cooling Fan: Supports
▪ 80 x 25 mm PWM Fan x 1
▪ 60 x 25 mm Rear Fan x 2
Expansion Slot: Full Height PCI Slot x 7
Material: Material: SGCC
Thickness: 1.0 mm
Packaging Dimensions (D x W x H): 692 x 633 x 294 mm
Shipping Information: Net Weight: 10.2 kg
Gross Weight: 17.9kg
Cubic Feet: 5.46
Container Info
▪ Single Packing: 20': 189pcs, 40': 378pcs, 40'H: 420pcs
