Note:

• The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
• These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
• These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.

Standard:

• IEEE 802.1p
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3x
• IEEE 802.3ab
• IEEE 802.3az

Device Interface:

• 24 x Gigabit ports
• LED indicators
• Power port

Data Transfer Rate:

• Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
• Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
• Gigabit Ethernet: 2000 Mbps (full duplex)

Performance:

• Switch fabric: 48 Gbps
• Ram buffer: 4 MB
• MAC Address Table: 8K entries
• Jumbo Frames: 9 KB

Special Feature:

• Supporting 802.1p QoS packet prioritization
• Up to 40% GREENnet energy savings

Power:

• Input: 100 - 240 V AC, 50/60 Hz, 0.8 A
• Output: 12 V DC, 1.5 A
• Consumption: 12 Watts (Max)

MTBF:

• 2,344,449 hours

Temperature:

• Operating: 0 – 40 °C (32 - 104 °F)
• Operating Humidity
• Max. 90% non-condensing

Dimensions:

• 251 x 158 x 48 mm (9.9 x 6.2 x 1.9 in.)

Weight:

• 1.6 kg (3.5 lb.)

Certifications:

• CE
• FCC

Warranty:

• 3 year limited
