Network processor

• Mellanox Connect X-3 Pro

Data rate

• Two ports, each at 20 Gbps bi-directional
• 40 Gbps aggregate bi-directional theoretical bandwidth.

Bus type

• PCI Express v3.0 (Gen 3) x8

Form factor

• PCIe Card

Power

• 6.2W Typical

Server supported

• ProLiant servers

IEEE compliance

• 802.3ae, 802.1Q, 802.3x, 802.1p, 802.3ad/LACP, 802.1AB(LLDP), 802.1Qbg, 802.1Qbb, 802.1Qaz

Compatible operating systems

• Windows:Microsoft Windows Server 2012, 2012 R2, 2008 R2 w/ SP1 (x64)Microsoft Windows Hyper-V 2008 R2 w/SP1, 2012, 2012 R2Linux:Red Hat Enterprise Linux 6.5 SUSE Linux Enterprise Server 11, SP3 (x64)HyperVisors:VMware ESXi 5.1 U2, 5.5 U1Citrix XenServer 6.5 (Creedence)Citrix XenServer (Naples) (x64)

Product differentiator

• Designed to optimize Cloud efficiency, and improve performance and security of applications – especially where I/O, block storage and database performance are critical and the need for maximum VM density and up-scalability are greatest.

Dimensions and weight

Dimensions (W x D x H):

• 5.71 x 24.13 x 19.05 cm (2.25 x 9.5 x 7.5 in)

Weight:

• 0.45 kg (1 lb)
