Picture/Display

LCD panel type: IPS-AHVA LCD

Backlight type: W-LED system

Panel Size: 27 inch / 68.6 cm

Effective viewing area: 596.7 (H) x 335.6 (V)

Aspect ratio: 16:9

Optimum resolution: 2560 x 1440 @ 60Hz

Response time (typical): 12 ms

SmartResponse (typical): 5 ms (Gray to Gray)

Brightness: 350  cd/m²

Contrast ratio (typical): 1000:1

SmartContrast: 50,000,000 :1

Pixel pitch:0.233 x 0.233 mm

Viewing angle:

• 178º (H) / 178º (V)
• @ C/R > 10

Picture enhancement: SmartImage

Display colors: Color support 1.07 billion colors

Color gamut: Adobe RGB 99%

Scanning Frequency: 30 - 83 kHz (H) / 56 - 76 Hz (V)

sRGB: Yes

Stand

Height adjustment: 150  mm

Pivot: 90 degree

Swivel: -65/65  degree

Tilt: -5/20  degree

Power

ECO mode: 25 W (typ.)

On mode: 36.95 W (typ.) (EnergyStar 6.0 test method)

Standby mode: <0.5 W (typ.)

Off mode: <0.3 W (typ.)

Power LED indicator:

• Operation - White
• Standby mode- White (blinking)

Power supply:

• 100-240VAC, 50-60Hz
• External

Weight

Product with stand (kg): 7.5  kg

Product with packaging (kg): 10.35  kg

Product with packaging (lb): 22.77  lb

Product with stand (lb): 16.50  lb

Product without stand (kg): 5.1  kg

Product without stand (lb): 11.22  lb

Sustainability

Environmental and energy:

• EPEAT Gold*
• PowerSensor
• EnergyStar 6.0
• RoHS
• TCO edge

Recyclable packaging material: 100  %

Post consumer recycled plastic: 65%

Specific Substances:

• PVC / BFR free housing
• Mercury free
• Lead free

Cabinet

Front bezel: Black

Rear cover: Black

Foot: Black

Finish: Texture

Connectivity

USB: USB 3.0 x 3

Signal Input:

• DVI-Dual Link (digital, HDCP)
• DisplayPort
• HDMIx2

Sync Input:

• Separate Sync
• Sync on Green

Audio (In/Out):

• PC audio-in
• Headphone out

Convenience

Built-in Speakers: 2 W x 2

Built-in webcam: 2.0 megapixel camera with microphone and LED indictor

MultiView:

• PIP/PBP mode
• 2x devices

User convenience:

• SmartImage
• Menu
• Multiview
• Power On/Off
• User

Control software: SmartControl Premium

OSD Languages:

• English
• French
• German
• Hungarian
• Italian
• Japanese
• Korean
• Polish
• Portuguese
• Russian
• Simplified Chinese
• Spanish
• Swedish
• Traditional Chinese
• Turkish
• Ukranian

Other convenience:

• Kensington lock
• VESA mount (100x100mm)

Plug & Play Compatibility:

• DDC/CI
• Mac OS X
• sRGB
• Windows 8.1 / 8 / 7

Dimensions

Product with stand(max height): 639 x 580 x 242  mm

Product without stand (mm): 639 x 405 x 64  mm

Packaging in mm (WxHxD): 750 x 234 x 490  mm

Packaging in inch (WxHxD): 29.5 x 9.2 x 19.3  inch

Product with stand(max height): 25.2 x 22.8 x 9.5  inch

Product without stand in inch: 25.2 x 15.9 x 2.5  inch

Operating conditions

Temperature range (operation): 0°C to 40°C  °C

Temperature range (storage): -20°C to 60°C  °C

Relative humidity: 20%-80  %

Altitude: Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF: 30,000  hour(s)

Compliance and standards

Regulatory Approvals:

• BSMI
• CE Mark
• cETLus
• FCC Class B
• GOST
• SASO
• SEMKO
• TCO 6.0
• TUV Ergo
• TUV/GS
• WEEE
• CU-EAC
